NyeMed® 7560
NyeMed® 7560 is a medium viscosity, UV-dyed, synthetic hydrocarbon grease formulated for medical applications that may require a biocompatible connector lubricant. This grease contains additives proven to protect electrical contacts against moisture and corrosive substances, and reduce mating force of connectors, ensuring signal transmission.
Advantages
- UV dye enhances tracing and visualization
- Very good resistance to oxidation and moisture
- Does not swell most plastics and elastomers
- Wide temperature range (-40 to 120°C)
Technical Properties
| Properties | Conditions | Typical Value | Test Method |
|---|---|---|---|
| Base Oil | - | Synthetic Hydrocarbon | - |
| Flash Point | - | > 310 °C | ASTM D92 |
| Base Fluid Apparent Viscosity | 25 °C 45 °C |
767 cP 260 cP |
Nye CTM |
| Color/Appearance | - | Light Yellow, Clear | Visual |
| Grease Apparent Viscosity | 25°C, 50/s shear rate | 27,500 | Nye CTM |
| Density | 25°C | 0.88g/cm³ | Nye CTM |
| Oil Separation | 24 h 100 °C | 1.5% | ASTM D6184 |
| Evaporation | 24 h 100 °C | 0.3% | ASTM D972 |
ISO 13485:2016 Certified
Nye Lubricants operates a Quality Management System that complies with the requirements of ISO 13485:2016. Our process controls, documentation, and quality standards meet or exceed all requirements for the design, manufacture, and distribution of synthetic lubricants for medical devices.
Backed By Biocompatibility Testing
| Test | Standard | Result | Meaning |
|---|---|---|---|
| Cytotoxicity L929 Agar Diffusion (Direct Contact) | ISO 10993-5 | Grade 0 | No Cellular Reactivity |
| Skin Irritation (Direct Contact) | ISO 10993-10 | Primary Irritation Index 0.0 | Negligible Irritant |
| Acute Systemic Toxicity (Direct Injection) | ISO 10993-11 | Negative | Pass |
Packaging Options
Nye greases are available in a variety of packaging sizes for both high-volume production dispensing and small volume dispensing.
- 30 cc syringe
- 55 cc syringe
- 153 cc cartridge
If these packaging options don't suit your needs, we will work with you to find you the right dispensing option for your application.
Want to learn more or place an order? Click here to contact an engineer.
