NyeTorr® 5200
Specialty lubricants improve the reliability of mechanisms within semiconductor manufacturing equipment to reduce maintenance and downtime. NyeTorr® 5200 is a soft, PTFE thickened, medium viscosity, Multiplyalkylated Cyclopentane (MAC) grease that has the lowest particle count of any NyeTorr® grease.
NyeTorr® 5200 is intended for cleanroom and in-vacuum components such as:
- Linear guides
- Ball & lead screws
- Bearings
- O-Rings
Advantages
- Good lubricity performance
- Excellent vacuum stability
- Low outgassing
- Extremely low particle generation
- Low vapor pressure
Lubricant Properties
| Properties | Test Conditions | NyeTorr® 5200 | Test Method |
|---|---|---|---|
| Chemistry | - | MAC / PTFE | - |
| Temperature Range | - | -45 to 150°C | - |
| Kinematic Viscosity | 40°C | 108 cSt | ASTM D-445 |
| Evaporation | 24 hrs, 100°C | 0% | Nye CTM |
| Oil Separation | 24 hrs, 100°C | 2.8% | ASTM D-6184 |
| Dynamic Particle Generation | 1200 RPM | ISO Class 3 | - |
| Vacuum Stability | 125°C, 7 x 10-3Pa, 24 hrs | Total Mass Loss= 0.068 wt% CVCM = 0.007 wt% |
ASTM E-595 |
| Knudsen Vapor Pressure | 25°C | 4x10-12 torr | - |
| SRV | 100N, 50Hz, 1mm stroke, 2 hrs, 40°C | Coefficient of Friction= 0.114 Ball Wear Scar = 0.44 mm |
ASTM D-5707 |
Packaging Options
NyeTorr® 5200 is available in:
- 10 cc and 30 cc white syringe
- 30 cc and 55 cc clear syringe
- 500 g and 1 kg jar
If your application requires a specific container, please contact us for custom packaging.
To learn more about the advanced properties of this grease click here. Ready to place an order? Contact an engineer.
